Product Description
Feature:
1.Weatherproof
2.Manual Override
3.Metal Gear Drive
4.All in one internal Motor and Weather Proof control panel
5.In some countries the cold climate, we add antifreeze oil inside the motor, It can work in an environment of – 25 °
Parameters:
1. Working temperature of motor:-45°C～ +55°C
2. Working humidity:≤85%
3. Power supply:220VAC±10%/110VAC±10% 50Hz/60Hz
4. Rated power:250W
5. Output gear module:M=4
6. Output gear number:Z=16
7.Output torgue:30.0 N.m
8. Open(close) speed:v=12m/min
9. Rated speed : 1400RPM
10. Maximum pull:1100N
11. Maximum load:1300KG
12. Net weight:12KG
13.Remote control distance : ≤50meter
14.Packing : In a carton
Functions of sliding gate motors:
1. Totally integrated electrical mechanical system (Quantity of racks optional ).
2. Control board interface for optional impact-proof infrared photocells.
3. Can connect flashing light and keypad and electric lock and so on.
4. Automatic delayed closing.
5. Adjustable resistance sensitivity.
6. Auto gate stop and re-open when an obstacle is encountered.
7. Wireless remote control or wired remote control are optional.
8. 24VDC sliding gate opener can connect transformer and back up battery.
